Crawler Excavator TW16 1.6T
EFFICIENT WORK WITH LOW EXPENSES
BEARING ENGINES
HIGH-QUALITY PARTS
SUITABLE FOR DEMANDING WORK ENVIRONMENTS
MODERN CABIN FOR COMFORT AND SAFETY
TW16 1.5T – a reliable and maneuverable mini tracked excavator, perfectly suited for various construction, agricultural, or landscaping tasks. Compact size, powerful hydraulic system, and economical engines allow work even in the most challenging conditions.
Main features
-
Laidong or Kubota water-cooled engines
-
4-stroke reliable mechanical engine
-
Powerful 20 MPa pressure hydraulic system
-
Compact dimensions for narrow passages
-
Reliable tracked base with support rollers
Technical Specifications – TW16 1.6T
| Parameter | Value |
|---|---|
| Model | TW16 |
| Operating weight | 1600 kg |
| Bucket capacity | 0.04 m³ |
| Dimensions (L x W x H) | 2550 x 1135 x 2200 mm |
| Minimum ground clearance height | 380 mm |
| Chassis length / width | 1500 mm / 230 mm |
| Wheelbase (ground contact) | 1190 mm |
| Travel speed (high / low) | 3.2 / 2.1 km/h |
| Swing speed | 12–13 rpm |
| Slope climbing ability | 58% |
| Ground pressure | 23 kPa |
Operating Parameters
| Parameter | Value |
|---|---|
| Max. digging radius (mm) | 3227 |
| Max. digging depth (mm) | 2000 |
| Max. digging height (mm) | 2900 |
| Max. dumping height (mm) | 2000 |
| Bulldozer blade lift height (mm) | 325 |
Engine Options
| Manufacturer | Model | Power (kW) | Cooling | Cylinders |
|---|---|---|---|---|
| Laidong | – | 29.0 | Water-cooled | 1 |
| Kubota | D722 | 10.4 | Water-cooled | 1 |
Hydraulic System
| Element | Value |
|---|---|
| Operating pressure | 20 MPa |
| Bucket digging force | 9.0 kN |
| Boom digging force | 5.5 kN |
| Carrier rollers (on each side) | 3 |
Fluid capacities
| Component | Capacity |
|---|---|
| Fuel tank | 14.5 L |
| Hydraulic system tank | 1.5 L |
| Engine oil capacity | 3.2 L |
Standard equipment
-
Laidong or Kubota engine
-
Standard 0.04 m³ digging bucket
-
Bulldozer blade
-
Crawler chassis
-
High-performance hydraulic system
